GG ISO

construction description

  • Louvre windows for installation in vertical facades

  • Frame and sash profifi les made from a thermally separated composite of aluminum and PA6.6 / PT profile

  • Filling made of double insulating glazing

  • Glazing framed on the side

  • Louvre windows consist of one or more louvres lying one on top of the other, which open as pivoting sashes via a horizontal axis of rotation. The part of the wing below the axis of rotation opens outwards and the part above it opens inwards. As a rule, the axis of rotation is in the middle of the slat height; can also be offset up to 1/3 –  2/3 after technical clarification(automated application only)

  • Standard with 78°(Bt50)/ 64°(Bt60) opening angle,
    if required also from 0° – 90°

profile dimensions

  • Frame depth: 50 mm or 60 mm (Dependent on application requirements)

  • Frame view width: 38 mm

  • View width of vertical wings: 33 mm

seals

  • Laterally with brush seal

  • Horizontal glass joints with silicone seal

fittings

  • Fittings are concealed

  • Made of corrosion-free materials or galvanized

Possible operations

Manually

  • Hand lever

  • Articulated crank rod

Motoric

  • 230V – AC

  • 24 V – DC (approved for NSHEV)

Pneumatic

  • Pneumatic cylinder (approved for NSHEV)

surfaces

  • Profiles anodised, powder or wet paint coated in RAL, NCS, DB or special colour

areas of application

  • For ventilation

  • As NSHEV according to DIN EN 12101-2

  • For installation in vertical facades (further applications after technical clarification) clarification)

Possible sizes

  • Minimum frame width: 300 mm

  • Maximum frame width: 1500 mm

  • As NSHEV up to 1000 mm (wider elements only with division by middle post)

  • Slat height variable: 200 mm to 350 mm

SPECIFICATIONS

MODEL

GG ISO

Profiles

Frame

Blade Holder

Thermally Broken

Thermally Broken

Dimensions

Frame Width

Frame Height

Louvre Blade Height

min. 300mm up to 1400mm

min. 300mm up to any height

min. 120mm up to 300mm

Glazing

Glazing Type

Makeup

Double Glazing

Up to 36mm

Finish

Powdercoated

Operation

Centre Pivot

24V Electric or Manual Operation

CERTIFICATION

AS2047

Water Penetration Test

Ultimate Strength Test

U-value

SHGC

Acoustics

150Pa

up to 7000pa

Subject to Glass Make-Up

Subject to Glass Make-Up

Subject to Glass Make-Up
